Downloads
Specification Sheet

RW

Product Details
Housing   Heavy wall extruded aluminum, internally sealed for weather proofing. Closed cell neoprene foam gasket is applied between lens frame and housing.
Lens   Clear tempered glass or drop prismatic polycarbonate or .125” clear polycarbonate sealed into mill finish aluminum frame with silicone. Lens frame is hinged and secured with two stainless quarter turn fasteners.
Reflector   Specular aluminum, available on type lll light distribution.
Ballast   High power factor - 20°C starting temperature. The ballast is removable as a unit for easy maintenance.
Arm Fitter   External cast aluminum slip fitter that accepts 2- 3/8” O.D. arm.
Finish   Polyester powder fuse coating is standard; other finishes are available upon request.

Ordering Information
1. Model Number
2. Wattage
3. Two Lamp
     L - Low Pressure Sodium
4. Voltage
     120, 208, 240, 277, 480
5. Lens
     FPL - Flat Poly Carbonate
     FGL - Flat Glass Lens
     DPL - Drop Prismatic Lens
6. Finish
     GY - Gray
     BZ - Bronze
     BK - Black
     ( Other color upon request)
7. Options
     RCP - Receptacle and Photo Control
     PC - Photo Cell

Variant Options
