Product Details |
Housing |
|
Corrosion resistant, cast A356 aluminum alloy, .188” min. wall thickness ballast compartment, and heavy gauge spun aluminum hood. |
|
|
|
|
Lens |
|
Flat tempered glass, convex tempered glass, or textured drop polycarbonate. |
|
|
|
|
Electrical |
|
All electrical components are UL approved. |
|
|
|
|
Ballast |
|
High power factor - 20°C starting temperature. The ballast is removable as a unit for easy maintenance. |
|
|
|
|
Reflector |
|
Segmented specular Alzak, available on type 1, 2, 3, FT and 5 light distribution when using flat or convex lens only. |
|
|
|
|
LED Engine |
|
All LED light boards and drivers are separate and removable for easy maintenance and replacement. |
|
|
|
|
Finish |
|
Polyester powder fuse coating is standard; other finishes are available upon request. |
|
|
|
|
|
|
Ordering Information |
1. Model Number 2. Wattage 3. Lamp Type H - Metal Halide S - High Pressure Sodium PS - Pulse Start CF - Compact Fluorescent* LED - Light-emitting diode IND - Induction 4. Voltage 120, 208, 240, 277, 480 and MT (Multi Tap) - 120, 208, 240, 277 5. Light Distribution 1, 2, 3, FT and 5 6. Lens FG - Flat Glass CG - Convex Glass TD - Texture Drop 7. Mounting Style 8. Arm Style 9. Finish BK - Black BZ - Bronze GR - Green VG - Verde Green ( Other color upon request) 10. Options HS - House Shield FS - Fuse PC - Photo Cell |
|
|
|
|
|
