Downloads
Specification Sheet

WB

Product Details
Housing   Heavy wall extruded aluminum, internally sealed for weather proofing. Closed cell neoprene foam gasket is applied between lens frame and housing.
Lens   Clear tempered glass, sealed into mill finish extruded aluminum frame with silicone. Lens frame is secured with stainless steel fasteners.
Electrical   All electrical components are UL approved.
Reflector   Specular aluminum.
Ballast   High power factor - 20°C starting temperature. The ballast is removable as a unit for easy maintenance.
Bold   Extruded aluminum, 360° adjustment.
Finish   Polyester powder fuse coating is standard; other finishes are available upon request.

Ordering Information
1. Model Number
2. Wattage
3. Lamp Type
     H - Metal Halide
     S - High Pressure Sodium
     PS - Pulse Start
     CF - Compact Fluorescent*
4. Voltage
     120, 208, 240, 277, 480 and
     MT (Multi Tap) - 120, 208, 240, 277
5. Finish
     BK - Black
     BZ - Bronze
     GR - Green
     VG - Verde Green
     ( Other color upon request)
6. Option
     FS - Fuse
     PC - Photo Cell
